Key Specifications
The system outputs high-power heating performance managed across individual components:
-
- Total Machine Power: 680W
- Soldering Iron Power: 75W
- Input Voltage: AC 220V / 110V (±10%; 50Hz / 60Hz)
- Hot Air Gun Temperature: 100°C to 480°C
- Soldering Iron Temperature: 200°C to 480°C
- Airflow Mechanism: Brushless fan supplying a gentle wind up to a maximum volume of 120 L/min
Core Features
-
- Microcomputer LCD Displays: Built with dedicated LED/LCD displays that show precise real-time temperatures for both the hot air gun and the soldering iron, alongside a separate digital layout tracking airflow speed.
- PID Temperature Control Technology: The system runs a programmatic loop every 20 milliseconds to detect the actual temperature at the soldering iron’s heating element, actively correcting discrepancies for rapid thermal recovery.
- Three-Speed Temperature Memory: Includes dedicated
CH1,CH2, andCH3channels to save distinct temperature and airflow configurations, allowing users to swap quickly between custom profiles. - Automatic On-Hook Sleep Function: Enhances safety and longevity by cutting off the heating element automatically when the hot air gun is resting inside its side-mounted holder, paired with an auto-cooling sequence.
- Built-in USB Charging Port: Offers an integrated interface on the front panel designed for testing or charging mobile devices on the fly.
