Key Features & Build
-
- Spring-Loaded Tension: Features an integrated spring mechanism on a guide rail that maintains firm, continuous pressure on the board without over-tightening or damaging delicate components.
- Three Movable Bayonets: Equipped with three adjustable card mouths/grooves. These can be configured side-by-side or adjusted independently to firmly grip irregular circuit board shapes.
- Anti-Deformation Design: The rigid metal construction helps absorb and distribute physical pressure, preventing thin mobile device motherboards from bending or bowing during disassembly and desoldering.
- Workstation Details: The heavy base plate features a non-slip colloidal backing to prevent sliding across your workbench. Some regional variants include utility integrations like built-in screwdriver docks or magnetic landing zones for small loose screws.
Technical Specifications
The fixture is distributed globally under multiple brand designations including KATEX, KC-101, and TE-07. Standard metrics include,
| Attribute | Specification |
|---|---|
| Material | Stainless steel and aluminum alloy components |
| Base Dimensions | Approximately 120mm x 80mm (roughly 4.7″ x 3.1″) |
| Max Capacity | Optimized for small circuit boards and mobile phone IC chips up to 70mm in width |
| Clamping Style | Dual horizontal slider tracking with precision screw lock positioning |
