⚙️ Core Technical Specifications
- Functionality: Drives up to two flash LEDs simultaneously.
- Output Current: Up to 1.5 A per channel (constant current source).
- Control Interface: Uses an I²C-compatible interface to adjust light parameters digitally.
- Dimming/Levels: Features a dual 128-level independent current adjustment to fine-tune the ratio between the two LEDs.
- Converter Architecture: Operates on a synchronous boost converter running at a fixed frequency of 2 MHz or 4 MHz.
- Input Voltage Range: Supports low-voltage operation starting from 2.5 V.
🛠️ Hardware & Protection Features
- Operating Modes: Features a high-power Flash mode and a lower-power Movie/Torch mode.
- Dedicated Control Pins: Includes hardware pins for STROBE (flash activation) and TORCH/TEMP.
- Thermal Management: Integrates an NTC thermistor monitor to safely track system temperature and prevent overheating.
- Circuit Protection: Equipped with built-in Overvoltage Protection (OVP) and adjustable current limits.
- Solution Size: Designed for high-frequency switching, allowing engineers to use ultra-small, low-profile external inductors and ceramic capacitors.
