Key Technical Specifications
- Power Output: 150W maximum.
- Voltage Range: Continuously adjustable from 0V to 30V DC.
- Current Range: 0A to 5A DC with high-precision 4-digit reading down to 1mA (0.001A).
- Transformer Type: Heavy-duty internal ring (toroidal) transformer built to sustain high temperatures without affecting the lifespan.
Standout Features
- Built-in Short Killer / Pulse Protection: Features a new pulse protection system. When combined with thermal imaging instruments, it allows brief high-current injections to isolate and heat up motherboard short circuits quickly for rapid debugging.
- High/Low Voltage Limited Lock: Dedicated 8.4V / 30V toggle switch. The 8.4V lock prevents accidental overvoltage damage when working on sensitive device logic boards and laptops.
- Massive USB Charging Matrix: Features 8 USB ports in total—6 intelligent adjustable USB output interfaces and 2 fixed 5V/2A charging outputs on the front and rear panels.
- Four Memory Channels: Buttons M1 through M4 allow you to save and instantly recall customized voltage, current limit, and overcurrent protection presets.
- Over-Current Protection (OCP): Includes modes for Continuous OCP and Once OCP to immediately cut off the current feed if a dangerous short circuit is encountered on the load.
