Key Specifications
- Voltage Measurement: AC up to 600V / DC up to 1000V.
- Current Measurement: AC 6A / DC 10A.
- Resistance: Up to 60MΩ.
- Capacitance: Up to 60mF.
- Temperature Testing: Range from -20°C to 1000°C.
- Sampling Rate: 3 readings per second.
- Dimensions: 142mm x 70mm x 32mm.
- Power Supply: 9V battery (typically not included in standard packaging).
Main Features
- Smart Auto-Ranging: Automatically recognizes AC/DC voltage, resistance, and continuity upon probing, making it highly beginner-friendly.
- Non-Contact Voltage (NCV) Detection: Safely detects live voltage without making direct contact with wires.
- Design & Build: Formed out of ABS fireproof, flame-retardant material with a comfortable grip. Its lightweight footprint easily fits into a pocket.
- Low-Light Utility: Built-in high-resolution LCD backlight display paired with a flashlight feature to inspect small components in dark areas.
- Additional Diagnostic Modes: Supports true RMS measurement, diode testing, data hold, and a continuity buzzer.
